In this post, I am sharing an important demonstration on how to improve query performance by adding Extended Statistics in PostgreSQL.
PostgreSQL: Important Statistics Table, Used by the Query Planner
The database statistics are always important in any database system. Because query optimizer is creating Query Execution Plan basis on stored database statistics.
Understand below official note which copied from here.
It is common to see slow queries running bad execution plans because multiple columns used in the query clauses are correlated.
The planner normally assumes that multiple conditions are independent of each other, an assumption that does not hold when column values are correlated. Regular statistics, because of their per-individual-column nature, cannot capture any knowledge about cross-column correlation.
Because the number of possible column combinations is very large, it’s impractical to compute multivariate statistics automatically. Instead, extended statistics objects, more often called just statistics objects.
Let me explain, by my way,
For example, you give two filters in a where condition like zip code and city_name.
Now, zip code is unique for dataset, but one city has multiple zip codes.
Now, this both conditions and columns called correlated columns.To inform the planner about functional dependencies, ANALYZE can collect measurements of cross-column dependency.
It is advisable to create dependencies statistics only for column groups that are strongly correlated, to avoid unnecessary overhead in both ANALYZE and later query planning.
Check the below demonstration:
Create a sample table:
|
1 2 3 4 5 6 |
CREATE TABLE tbl_TestStats ( ID SERIAL ,CodeDate TIMESTAMPTZ ,CodeName TEXT ); |
Two sample insert for different series:
For example, 2016 year for code ‘abc’ and 2017 year for code ‘xyz’
|
1 2 3 4 5 6 7 8 9 10 |
INSERT INTO tbl_TestStats (CodeDate, CodeName) SELECT x, 'abc' FROM generate_series('2016-01-01 00:00:00'::timestamptz, '2016-12-31 00:00:00'::timestamptz,'10 seconds'::interval) a(x); INSERT INTO tbl_TestStats (CodeDate, CodeName) SELECT x, 'xyz' FROM generate_series('2017-01-01 00:00:00'::timestamptz, '2017-12-31 00:00:00'::timestamptz,'10 seconds'::interval) a(x); |
Total inserted records:
|
1 2 |
SELECT COUNT(1) FROM tbl_TestStats -- '6298562' |
Now, Execute ANALYZE:
|
1 |
ANALYZE tbl_TestStats; |
Check the execution plan of the below query:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 |
EXPLAIN ANALYZE SELECT *FROM tbl_TestStats WHERE CodeDate = '2016-12-03' AND CodeName = 'abc' 'Gather (cost=1000.00..80484.88 rows=1 width=16) (actual time=347.355..347.496 rows=1 loops=1)' ' Workers Planned: 2' ' Workers Launched: 2' ' -> Parallel Seq Scan on tbl_teststats (cost=0.00..79484.77 rows=1 width=16) (actual time=278.702..340.557 rows=0 loops=3)' ' Filter: ((codedate = '2016-12-03 00:00:00+05:30'::timestamp with time zone) AND (codename = 'abc'::text))' ' Rows Removed by Filter: 2099520' 'Planning time: 0.168 ms' 'Execution time: 353.298 ms' |
Now, Create an Extended Statistics for correlated columns:
|
1 2 |
CREATE STATISTICS Ext_Stat_tbl_TestStats (dependencies) ON CodeDate, CodeName FROM tbl_TestStats; |
Now, Execute ANALYZE:
|
1 |
ANALYZE tbl_TestStats; |
Check execution plan for the same query:
Comparing to first result, you can find slightly performance improvement in the second result.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 |
EXPLAIN ANALYZE SELECT *FROM tbl_TestStats WHERE CodeDate = '2016-12-03' AND CodeName = 'abc' 'Gather (cost=1000.00..80484.86 rows=1 width=16) (actual time=150.732..311.567 rows=1 loops=1)' ' Workers Planned: 2' ' Workers Launched: 2' ' -> Parallel Seq Scan on tbl_teststats (cost=0.00..79484.76 rows=1 width=16) (actual time=251.261..304.857 rows=0 loops=3)' ' Filter: ((codedate = '2016-12-03 00:00:00+05:30'::timestamp with time zone) AND (codename = 'abc'::text))' ' Rows Removed by Filter: 2099520' 'Planning time: 0.167 ms' 'Execution time: 316.685 ms' |
